Speaker, Outdoor, 70W@16Ω, 60W@100V | Audac WX802Mk2/O

Corrosion-resistant 2-way outdoor speaker with excellent sound quality and power handling. Powder-coated aluminium and ABS construction. Aluminium mounting bracket included.

Warranty: 1-year

This product is currently out of stock and unavailable.

Brand: SKU: WX802Mk2/O Category:

Key Features

  • RMS power ratings of 70 Watts @ 16 ohms and 60 Watts @ 100 Volts
  • 16 Ohm impedance allows multiple speakers to be connected in parallel to one amplifier
  • Built-in 100 Volt line transformer with multiple power tappings provides even greater connection versatility
  • 8-inch woofer in a reflex enclosure provides deep punchy bass
  • Crystal clear treble from a 1-inch dome tweeter
  • Well-designed crossover circuit provides smooth overall response
  • Plastic and aluminium construction – will withstand beach-side use for years
  • Aluminium mounting bracket included
  • Waterproof cable connection
  • IP55 rated

Specifications

Speaker type2-way bass reflex
Max. Power140W
RMS Power70W
Impedance16Ω / 167Ω / 333Ω / 667Ω
Sensitivity (1W/1m)89dB
Ingress Protection RatingIP55
ConnectorsWaterproof AWX-5 connector
Line Transformer Tappings60W @ 167Ω, 30W @ 333Ω, 15W @ 667Ω
Sound Pressure (Max. W/1m)@ 16Ω: 108dB
@ 100V: 106dB
Frequency Response (±3 dB)60Hz ~ 17kHz
Frequency Range (-10 dB)50Hz ~ 20kHz
Crossover Frequency2.4kHz
DispersionHorizontal:
Vertical: 110°
DriversHF: 1” dome tweeter
LF: 8” cone woofer
Dimensions270 x 360 x 215 mm (W x H x D)
Weight7.5kg
Operating temperature-25°C ~ 70°C
Cabinet MaterialABS
Front GrillePowder Coated Aluminium
Colors AvailableBlack (RAL9005) and White (RAL9003)
Included AccessoriesMounting bracket
5-pin connection cable (70 cm)
Optional AccessoriesAU570120005 – 5-pin cable 0.5 m
AU570120025 – 5-pin cable 2.5 m
AU570120050 – 5-pin cable 5 m
